Dell S2522HG 24.5" (25") 25 Gaming Monitor Full HD 240Hz,1ms Response Time,Fast IPS Panel
- Product SKU: S2522HG
- Category: Computers and Peripherals, Dell, Featured, Monitors
Dell S2522HG 25" 25 Gaming Monitor Full HD 240Hz,1ms Response Time,Fast IPS Panel
Specification
Display
Diagonal Viewing Size:
- 62.20 cm
- 24.5 Inches
Preset Display Area (H x V)
- 543.74 mm x 302.62 mm
- 21.40" x 11.91"
- 164,545.63 mm2 (255.05 inches2)
Panel Type:
- Fast IPS
Maximum Preset Resolution
- 1920 x 1080 at 240Hz
Display Screen Coating
- Antiglare with 3H hardness
Viewing Angle
- (178° vertical / 178° horizontal)
Pixel Pitch
- 0.2832 x 0.2802 mm
Pixel Per Inch (PPI)
- 90
Contrast Ratio
- 1000: 1 (Typical)
Aspect Ratio
- (16:9)
Backlight Technology
- LED edgelight system
Brightness
- 400 cd/m2 (typical)
Response Time (typical)
- 1ms (gray to gray) in Extreme mode
NVIDIA® G-SYNC® Compatible
- Yes
NVIDIA® G-SYNC® Compatible Certification
AMD Free-Sync™ Premium Technology
- Yes
- Supports AMD FreeSync Premium™ Technology
Lighting
- Downlights
Adjustability
- Height adjustable stand (130 mm)
- Tilt (-5° to 21°)
- Swivel (-45° to 45°)
- Pivot (-90° to 90°)
Built in cable-management
Dell Display Manager Compatibility
- Yes
Low Blue Light
- Yes, ComfortView
Flicker-free
- Yes
Color Support
Color Gamut (typical):
- sRGB 99%
Color Depth:
- 16.7 Million colors
Built-in Devices
- NA
Audio Output
- No
Connectivity
- 2 x HDMI (ver 2.0)
- 1 x DP (ver 1.2)
- 1 x SuperSpeed USB 3.2 Gen1 (5Gbps) upstream port (rear)
- 2 x SuperSpeed USB 3.2 Gen1 (5Gbps) downstream ports [Front bottom, one with BC1.2 charging capability at 2A (max)]
- 2 x SuperSpeed USB 3.2 Gen1 (5Gbps) downstream ports (rear)
- 1 x Headphone-out jack
Dimensions & Weight
Flat Panel Mount Interface
- VESA (100 mm)
Height with stand (Compressed ~ Extended)
- 375.75 mm ~ 505.75 mm
- 14.79 inches ~ 19.91 inches
Width
- 555.40 mm
- 21.87"
Depth
- 200.3 mm
- 7.89 inches
Height without stand
- 327.24 mm
- 12.88"
Width without stand
- 555.4 mm
- 21.87"
Depth without stand
- 68.38 mm
- 2.69"
Weight (panel only - for VESA mount)
- 3.72 Kg
- 8.20 lb
Weight (with packaging)
- 8.54 Kg
- 18.82 lb
Power
Voltage Required
- 100 to 240 VAC / 50 or 60 Hz ± 3Hz / 1.5 A (typical)
Altitude Operating
- Operating: 5,000 m (16,404 ft) max
- Non-Operating: 12,192 m (40,000 ft) max
Temperature Range
- Operating: 0° to 40°C (32° to 104°F)
- Non-operating: -20° to 60° (-4° to 140° F)
Humidity Range
- Operating: 10% to 80% (non-condensing)
- Non-Operating: 5% to 90% (non-condensing)
Power Consumption
- 0.3W (Off Mode)
- 0.3W (Standby Mode)
- 16.8W (On Mode)
- 72W (Max)
- Energy Efficiency
Warranty
- Specifications - Service / Support Details
- 3-Year Advanced Exchange Service and Premium Panel Exchange
In The Box
- Monitor
- Stand riser and base
- Power cable
- DisplayPort to DisplayPort (ver 1.2) cable
- HDMI (ver 2.0) Cable
- SuperSpeed USB 5Gbps (USB 3.2 Gen1) upstream cable
- Quick setup guide
- Safety Information
